10/100M GEPON ONU with 1 100M RJ45 Port FTTH WIFI ONU

Qty (Piece/Pieces)	Unit Price (1.0~60.0 USD)
1	1
1 +	60
Trade Term:	EXW
Payment Terms:	T/T,WU
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: HA404WS

Production Capacity: 10000 Pieces per Month

Delivery Date: in one week

Name: GEPON ONU

Colour: white

TP Ports: 1 10/100Mbps RJ45 port

Certificates: CE/RoHS/ISO9001:2008

Means of Transport: Ocean,Land,Air

Packing: standard packing

Brand Name: HiOSO

Material: plastic

Rate: 10/100Mbps

WIFI: support

HA404WS is a indoor version Ethernet ONU, mainly applied for FTTH/FTTO network. HA400WS supplies 4 fixed 10/100Mbps Ethernet ports, supporting WIFI.

Overview

HA404WS is a indoor version Ethernet ONU, mainly applied for FTTH/FTTO network. HA400WS supplies 4 fixed 10/100Mbps Ethernet ports, supporting WIFI function.

Feature

Apply to IEEE802.3/802.3ah

Support auto discovery and auto register (real-time operation)

Support DBA and multi types SLA

Support ONU auto discovery/link detection/remote upgrade

Support IEEE802.1D RSTP

Support IGMP Snooping V2 multi-broadcast function

Support EMI and ESD identification

64bit MAC

Support VLAN

Support multi LLID

Support user end auto time synchronization based at SNTP

Integrate CATV optical receiver

Support OAM and remote management

Technical Specification

Parameter	Specification
Wavelength	1310(TX)/1490(RX)
Optical power	-1~+4dBm
Receiving sensitivity	-24dBm
Maximum transmission distance	20 km
Cache space	1.25MB
MTBF	100,000 hours
PON port	SC/PC
Feature	Support IEEE802.3ah Support Dynamic Bandwidth Allocation (DBA) Support ONU auto-searching and automatic registration (real-time operation)
Standards	Support IEEE802.3, IEEE802.3u Support IEEE802.1q VLAN Support IEEE802.1p QOS IEEE802.11b/g/n
Management	Cooperating with center OLT, implement management configuration and software upgrade to ONU

Working environment

Parameter	Specification
Power	DC12V/1A
Power consumption	3.5W
Working temperature	0～50℃
Storage temperature	-40～85℃
Humidity	5%～90% non-condensing
Dimension	32.5mm(H) × 160mm(W) × 120mm(D)
